Removed features: - The "--bpp" command line option and related code (i.e. the renderin functions for 16 bits-per-pixel host screens) have been removed since almost all recent hardware should support 32 bpp nowadays Configuration changes: - In hatari.cfg, section [RS232], rename: - sSccBOutFileName => SccBOutFileName - bEnableSccB => EnableSccB Emulation improvements: - MFP: - When IRQ is cleared on one of the 2 ACIAs, do not clear IRQ on the MFP side if the IRQ is still set on the other ACIA - Blitter: - Ignore byte accesses to blitter registers defined as word only - TT/DMA: - Update sound FIFO on each HBL (like on STE) - CPU: - Sync CPU core with WinUAE CPU core 5.2 beta - Improved 68000 cycle accuracy (IPL, STOP, TRACE) - Fix IACK timings - Return vector=24 if a spurious interrupt happens during the IACK sequence - 68010 DIV overflow undefined flags update - NMI handling - MMU/generic CPU mode autovectored interrupt support - Fix 68060 MMU MOVEM.L (An)+, if regs contain An - 68040/060 MMU fault handler bug fix for MOVEM - Fix FSINCOS and FMOVE.L/FMOVEM.L register in disasm - Some softfloat fixes - Fix stacked PC for branch/jump instructions doing a bus error - DSP: - Fix: effective address with modifier=modulo - Add host interface initialisation - Add host received data interrupt - Improve bootstrap support - Video: - Add support for 4 pixel hardscroll on STF by stopping shifter with $FF8260=3 (new technique by Troed/Sync) - In monochrome mode correctly mask the video address to 22 or 24 bit space depending on the machine type. Prevent crash in some cases when Hatari is compiled with "small mem" option - Fix VBLANK location, should be line 308 on 50 Hz (was 307 before) - SCC 85C30 (for MegaSTE, TT and Falcon) - Major rewrite of most of the code, should support all modes used by TOS and EmuTOS or when accessing SCC's registers directly - Support all serial ports as well as LAN port for MegaSTE and TT - Joypads: - STE joypad emulation now supports analog / paddle input, too - FDC: - For IPF/CTR support, caps library has a bug that resets FDC's TR and DR on warm reset (68000's reset command). We keep/restore the value ourselves - IDE: - Fixed emulation of the HOB (High Order Byte) of the last LBA48 value - LBA28 capacity announcement is now correctly limited to 2^28-1 - Falcon: - DMA sound : fix SNDINT/SOUNDINT values (0=playing, 1=idle) and interrupts on TAI / GPIP7 for start of frame / end of frame - Preliminary support for more vertical refresh rates (50,60 or 71 Hz) based on Videl's registers $FF82C0 (VCO) and $FF82A2 (VFT) (was only 50 Hz before) Emulator improvements: - TOS: - Fix: set TOS country code from CountryCode setting, not Language one - Add "pl" (Poland) & "ro" (Romania) language options for EmuTOS - RTC: - CLI/config option to override NVRAM/RTC year, useful with applications that do not handle current dates - Joystick/Joypad support: - Fix: joystick button 2 space key emulation "autofiring" - Keyboard emulation support for all STE joypad buttons/keys - Support for re-mapping joystick buttons - GEMDOS HD: - Fix: Fread/Fwrite combination on Windows - Fix: Frename() should fail when target exists - Support up to 64 simultaneously open files (earlier limit was 32) - Similarly to TOS, allow programs to write to a file they have opened as read-only (by opening all writable files as read/write). As this could fail with real HW under MiNT/MagiC, show warning about it - Screen: - Support for screenshot using .NEO or .XIMG format - Add option "--screenshot-format " ( = png or bmp or neo or ximg) - Memory Snapshot: - Add some missing variables to the savestate - Logging/tracing: - "os_base" trace option outputs now also dir create/delete + file delete calls (in addition to earlier pexec/pterm & file create/open calls) - Separate CPU video cycles under its own "cpu_video_cycles" trace flag - Suppress repeats of identical log & trace messages by default (show only their count) and add "--msg-repeat" option to toggle that - Debug symbol handling: - Fix: invalid free on freeing loaded GNU debug symbols - Fix: Do not limit "A" type (constant) symbol values to 24-bit - Add support for reading symbols from new MINT+ELF binaries - Add support for demangled C++/a.out symbols (which can be very long and contain almost any characters) - ".sym" file beside program file acts as its symbols override - Add optional argument for "symbols " commands, to limit listed symbols to ones with the given substring - Improved support for weak symbols (important for C++ code) - Symbols with duplicate addresses are skipped on symbols loading - Disassembler: - Fix: CPU core disassembler crashes with longer symbol names - When entering debugger with 'history' enabled, disassembly address defaults to an address in history preceding the PC register value (to give more context than disassembling directly from PC) - Support for disassembly output options working also for CPU core disassembler, in addition to external disassember output - More flags to change the disassembly output for CPU core (upper/lower case, show memory content, show EA, ...) - The built-in "external" disassembler has been replaced by a disassembler provided by the Capstone library (version >= 4.0) - Debugger: - Fix: free all debugger allocations before exit - Fix: memdump command always outputs only requested number of items - Add address width (addr).[bwl] support to expression evaluation - History skips address repeats (e.g. with "stop" instruction) - Breakpoint ":quiet" option inhibits also extra output when ":file" option debugger command file is parsed - Line-A and line-F exceptions can be caught with "--debug-except" option (in addition to breakpoints) - Add "echo" command with escape handling, so that one can e.g. use "echo \ec" to clear (ANSI) terminal before breakpoint output from a debugger command file GUI improvements: - SDL GUI: - Fix: mouse not visible in floppy disk dialog when it is invoked from a keyboard shortcut in fullscreen mode - Fix: fileselector scrollbar works with mouse also in SDL2 scaled / fullscreen window - Support for joystick button mapping + space key vs. jump option - Mac GUI: - Accept all file names as Mac file selector does not show a list of the accepted file name extensions any more Tools: - gst2ascii: - Support for new MINT+ELF symbols - "-o" option is split to "-f" and "-g" options - "-s" option to skip symbols with duplicate addresses - By default filters same symbols out as Hatari debugger - This can be reverted with new '+' option variants (+l +g +s) - More concise listing of the duplicate symbols - Profile data post-processor: - Does not show (most) of symbol conflict messages any more (unless '--verbose' option is given) - When address has multiple symbols which names are thought as C/C++ symbols, prefer shortest one - Support for symbol files + Hatari profile data containing demangled C++ symbols - Support weak symbols (used for C++ template methods) - Overtly long C++ symbol names are shortened in callgraphs (unless '--full-symbols' option is given) - Symbols given for "--only", "--ignore" and "--ignore-from" are interpreted as match patterns (with '*?[]' wildcards) - Only single arrow shown between callgraph nodes when "--compact" option is used - m68k-instructions: (new) - Tool for printing m68k instruction breakpoints & opcode info Build improvements: - Fix: CPU core compile warnings (WinUAE upstream) - Fix: groff/troff warnings for manual pages - Use cmake config file provided by the SDL2 library instead of trying to detect the SDL2 library ourselves (fixes compilation on macOS) - Removed unused sources for HD6301 emulation - Hatari can now be compiled with emscripten, too Fixed demos: - Chaos A.D. : bad sound (Falcon DMA sound interrupts) - Little -ME- Demo end part by Overlanders : black screen after a while (IACK timing) - Monscape : bad sound (TT/DMA FIFO update) - Time Slice by Defence Force : monochrome demo (crash when Hatari is compiled with "small mem" option) - What If by Troed/Sync : 4 pixel hardscroll on STF by stopping shifter - Oergs, Terrorize your soul, Zero Three Zero demos work now also when MMU is enabled Fixed programs: - FlaySID (DSP host handling) - AFM sound with equalizer enabled (DSP modulo) - FreeMiNT (use SCC counter at start to detect the SCC clock freq) - Spectre 3.0 Macintosh emulator (stacked PC in case of bus error) - m68k-Linux works (again) with 040/060 emulation (MMU) - m68k-NetBSD does not crash on boot any more (MMU) Fixed games: - F29 Retaliator using CTR/IPF format (handle FDC's TR reset bug in caps library) - MIDI (MFP IRQ clear) handling: - Bad Mood - Midi Maze - Midi Maze II - Oxyd 2 - Work now also when MMU is enabled: - Gravon (demo) - Killing Impact - Moongame

ZIP file support - ROM Selection window can navigate into zip files ARM Additions - Profiling can now be viewed as 'cycles / call' - this shows the relative performance of a single call to the program's function - Distinguishes between memory alignment requirements for different ARM architectures - ARMv4 doesn't allow misalignment at all and will access an aligned address instead - ARMv7 does allow misalignment depending on the instruction - recent versions of Gopher2600 incorrectly assumed a ARMv7 architecture, which leads to incorrect Harmony emulation - Misaligned memory accesses optionally treated as memory faults - when enabled misalignment is reported in the memory faults window - and will cause execution to abort if Abort of Memory Fault option is enabled - Strobing of local variables in local variables window - Added COPROC MEM DUMP - also accessible through context menu in static memory window ARM Corrections / Bug Fixes - Static memory window performance improvement - ASR disassembly corrected - COPROC ID corrected - 32bit EOR (register) instruction - Allocation of instruction to source lines uses EndSequence flag in DWARF line entry - this improves startup time and removes trailing instructions from functions - Disassembly of 32bit instructions - instructions following a 32bit instruction had the wrong address - More accurate identification of VCS "kernel" in which ARM code is being executed Other Bug fixes - Fixed supercharger mutliloading for 'fastload' binaries - PlusROM network transmission - Corrected reflection of HMOVE information - a new HMOVE would be noted in the reflection overlay but it would never be cleared Other Changes - Notification icons and FPS window - ARM developer icon moved to the FPS overlay - FPS window now shows multiple icons if required - Mouse wheel works for rewinding in the debugger - moves in 10 frame increments. hold shift-key for single frame increments

- Apple2: Fixed erroneous parsing of WOZ file padding bytes and unknown chunks' data as 8-byte chunk headers. Fixed broken handling of the end-of-stream condition when reading from non-compressed files stored in ZIP archives; fixes loading of such Apple II WOZ disk images and CloneCD CD images - SS: Implemented workaround for gcc bug #113255 in the VDP1 rasterization code - Apple2: Fixed typos/brainfart that broke language card and ROM card control accesses via $C08F

- UI: implement an option to pause the emulator when the window is inactive - UI: improve lack of response to input changes in the sprite viewer when the emulator is paused - UI: replace QOpenGLWidget with QWidget - UI: fix solar sensor level menu that has been broken in 1.8.0 - GPIO: fix broken deserialization of port directions - APU: MP2K HLE: handle corrupted wave info addresses - APU: PSG L/R volume must be remapped from 0-7 to 1-8 - GameDB: Japanese Boktai releases have a solar sensor - Redirect stdout on Windows

General: - Fixed GLSL version parsing on some OpenGL ES2 platforms - Don't try to use shaders on old OpenGL implementations AGI: - Fixed Space Quest 1 version 1.0X freezing in the skimmer - Fixed Mixed-Up Mother Goose message boxes during nursery rhymes - Fixed Mixed-Up Mother Goose graphics in Amiga version - Fixed Gold Rush clock time at Fast and Fastest speeds - Fixed Atari ST version of Manhunter 1 not starting - Fixed Tandy CoCo3 version of Leisure Suit Larry 1 not starting - Fixed Tandy CoCo3 unofficial ports not starting - Fixed Amiga menus in Space Quest 1, Manhunter 1, and Manhunter 2 - Fixed Graham facing away from the king in King's Quest 1 - Fixed Alexander getting stuck on the stairs in King's Quest 3 - Fixed Larry being able to shoplift in Leisure Suit Larry 1 - Fixed ducks not jumping at the start of Donald Duck's Playground - Fixed instant death in fan game "Phil's Quest: The Search for Tolbaga" - Fixed buttons freezing in fan game "DG: The AGIMouse Adventure" - Fixed unrecognized words in fan game "V - The Graphical Adventure" - Added detection for Macintosh version of Mixed-Up Mother Goose AGS: - Updated detection tables - Simplified character import from Sierra games for QfG2 AGDI - Fixed graphical glitch affecting Unavowed and Heroine's Quest - Fixed partial outlines for some letters in Kathy Rain - Fixed crash in Alum - Added stub to prevent crash at the beginning of Falcon City Broken Sword 2: - Fixed crash when quitting the game while it was paused MM: - Enabled engine, allowing MM1 and Xeen to be compiled - Added MT32/LAPC-1 support for Xeen engine - Fixed Xeen regression which caused some sound effects to stop abruptly mTropolis: - Fixed crash in Muppet Treasure Island on some platforms - Fixed jewel puzzle in Muppet Treasure Island not being randomized NANCY: - Fixed the telephone hints in Secrets Can Kill - Fixed the crashing and drawing issues on ARM machines when playing Message in a Haunted Mansion's maze minigame - Fixed the 'M' keyboard key not working in Message in a Haunted Mansion - Allowed general keymaps to be shown in the engine Keymaps menu - Virtual keyboard now correctly triggers on/off wherever text input is needed SCUMM: - Fix screen corruption (and sometimes even crashes) in Mac Loom and Indiana Jones and the Last Crusade, most noticeably when using menu shortcut keys - Fix enabling/disabling of Open and Save in Mac Indiana Jones and the Last Crusade TWINE: - Fix ladder climbing regression - Fix scenery zoom issue - Fix animation glitches after using the holomap Ultima: - Fix Ultima VIII hidden minimap blocking keyring use - Fix Ultima VIII page breaks in books - Fix Ultima VIII text centering for plaques - Fix Ultima VIII crash on dragging items to screen edge - Fix Ultima VIII unexpected jumping on left click - Fix Ultima VIII camera during cutscenes for Shrine of the Ancient Ones - Fix Ultima VIII invalid placement of items within containers - Fix Ultima VIII never-ending lava sounds V-Cruise: - Fixed crash in Reah: Face the Unknown and Schizm: Mysterious Journey when music is muted Android port: - Fixed crash in built-in help with German language Atari port: - Fixed crash when exiting ScummVM - Fixed BBVS (and possibly others) gameplay by using more precise math model macOS port: - Fixed a problem where some Mac games would not load resources correctly - Updated application icon to conform with modern standards

User interface - Fixed exit confirmation incorrectly disabled by ACPI shutdowns - Fixed missing translations on some error messages related to hard disk images - Updated translations: Chinese (Simplified), Chinese (Taiwan), Japanese, Korean Machines - Added IBM Aptiva 510/710/Vision Socket 3 machine - Added NEC Mate NX MA23C Socket 7 machine - Added PC Chips M747 Slot 1 machine - Added AGP support to the MSI MS-5172 - Fixed BIOS error caused by serial passthrough on the IBM PS/2 Model 70 - Fixed Gigabyte GA-5SG100 filed on the wrong category (now Super Socket 7) - Changed maximum CPU speed on the Hyundai SUPER-16T to 8 MHz Hardware Core - Fixed operating system crashes related to the LOCK instruction on 386 CPUs only Display - Added Trident TVGA 8900D-R ISA video card (faster 8900D) - Added more BIOS options to the Tseng ET4000AX ISA video card - Fixed Voodoo 3D glitches in several games, especially on 64-bit builds - Fixed 1600x1200 resolution availability through DDC data on older operating systems - Fixed Tseng ET4000AX and ET4000/W32 rendering issues with specific resolutions - Fixed several rendering issues on S3 86C801 and 86C805 cards - Fixed Linux cursor issues on Matrox cards - Fixed specific video playback acceleration glitches on S3 ViRGE cards - Changed maximum video memory on the STB PowerGraph 64 Video to 2 MB to match real cards Sound - Improved OPL2 and OPL3 sound quality - Fixed base Sound Blaster AWE64 incorrectly identifying as a Value Storage - Added McIDE IDE disk controller for MCA machines - Added Vision Systems LBA Enhancer add-on ROM - Added German and newer English BIOS options to the Adaptec AHA-154xCP SCSI controller - Fixed instability issues with ESDI disk controllers, particularly MCA ones - Fixed floppy drive controller inaccuracy crashing 386BSD and FlexOS 286 Other - Added Everex Magi Magic EV-165A ISA memory expansion card
